Rockwell Automation Publication 20C-PM001F-EN-P - March 2012 59
Programming and Parameters Chapter 2
217 Dig Out Status Diagnostics 2-40
218 Drive Temp Diagnostics 2-40
220 Motor OL Count Diagnostics 2-40
224 Fault Frequency Diagnostics 2-40
225 Fault Amps Diagnostics 2-40
226 Fault Bus Volts Diagnostics 2-40
227, 228 Status X @ Fault Diagnostics 2-41
229, 230 Alarm X @ Fault Diagnostics 2-41
234, 236 Testpoint x Sel Diagnostics 2-42
235, 237 Testpoint x Data Diagnostics 2-42
238 Fault Config 1 Faults 2-42
240 Fault Clear Faults 2-42
241 Fault Clear Mode Faults 2-42
242 Power Up Marker Faults 2-42
243 Fault 1 Code Faults 2-43
244 Fault 1 Time Faults 2-43
245 Fault 2 Code Faults 2-43
246 Fault 2 Time Faults 2-43
247 Fault 3 Code Faults 2-43
248 Fault 3 Time Faults 2-43
249 Fault 4 Code Faults 2-43
250 Fault 4 Time Faults 2-43
251 Fault 5 Code Faults 2-43
252 Fault 5 Time Faults 2-43
253 Fault 6 Code Faults 2-43
254 Fault 6 Time Faults 2-43
255 Fault 7 Code Faults 2-43
256 Fault 7 Time Faults 2-43
257 Fault 8 Code Faults 2-43
258 Fault 8 Time Faults 2-43
259 Alarm Config 1 Alarms 2-44
261 Alarm Clear Alarms 2-44
262 Alarm 1 Code Alarms 2-44
263 Alarm 2 Code Alarms 2-44
264 Alarm 3 Code Alarms 2-44
265 Alarm 4 Code Alarms 2-44
266 Alarm 5 Code Alarms 2-44
267 Alarm 6 Code Alarms 2-44
268 Alarm 7 Code Alarms 2-44
268 Alarm 8 Code Alarms 2-44
271 Drive Logic Rslt Comm Control 2-45
272 Drive Ref Rslt Comm Control 2-45
273 Drive Ramp Rslt Comm Control 2-45
274 DPI Port Sel Comm Control 2-46
275 DPI Port Value Comm Control 2-46
276 Logic Mask Masks/Owners 2-46
277 Start Mask Masks/Owners 2-46
278 Jog Mask Masks/Owners 2-46
279 Direction Mask Masks/Owners 2-46
280 Reference Mask Masks/Owners 2-46
281 Accel Mask Masks/Owners 2-46
282 Decel Mask Masks/Owners 2-46
283 Fault Clr Mask Masks/Owners 2-46
284 MOP Mask Masks/Owners 2-46
285 Local Mask Masks/Owners 2-46
288 Stop Owner Masks/Owners 2-47
289 Start Owner Masks/Owners 2-47
290 Jog Owner Masks/Owners 2-47
291 Direction Owner Masks/Owners 2-47
292 Reference Owner Masks/Owners 2-47
293 Accel Owner Masks/Owners 2-47
294 Decel Owner Masks/Owners 2-47
295 Fault Clr Owner Masks/Owners 2-47
296 MOP Owner Masks/Owners 2-47
297 Local Owner Masks/Owners 2-47
300-307 Data In XX Datalinks 2-47
310-317 Data Out XX Datalinks 2-48
320 Anlg In Config Analog Inputs 2-49
321 Anlg In Sqr Root Analog Inputs 2-50
322, 325 Analog In X Hi Analog Inputs 2-50
323, 326 Analog In X Lo Analog Inputs 2-50
Number Parameter Name Group Page
324, 327 Analog In X Loss Analog Inputs 2-50
340 Anlg Out Config Analog Outputs 2-50
341 Anlg Out Absolut Analog Outputs 2-51
342, 345 Analog OutX Sel Analog Outputs 2-51
343, 346 Analog OutX Hi Analog Outputs 2-51
344, 347 Analog OutX Lo Analog Outputs 2-51
354, 355 Anlg OutX Scale Analog Outputs 2-51
358 20C-DG1 Remove Digital Inputs 2-52
359 20C-DG1 Status Digital Inputs 2-52
361-366 Digital InX Sel Digital Inputs 2-53
377, 378 Anlg OutX Setpt Analog Outputs 2-51
379 Dig Out Setpt Digital Outputs 2-54
380, 384,
388 Digital OutX Sel Digital Outputs 2-54
381, 385,
389 Dig OutX Level Digital Outputs 2-55
382, 386,
390 Dig OutX OnTime Digital Outputs 2-55
383, 387,
391 Dig OutX OffTime Digital Outputs 2-55
454 Rev Speed Limit Speed Regulator 2-25
460 PI Reference Hi Process PI 2-29
461 PI Reference Lo Process PI 2-29
462 PI Feedback Hi Process PI 2-29
463 PI Feedback Lo Process PI 2-29
464 PI Output Gain Process PI 2-29
465 Fan Control Stop/Brake Modes 2-32
543 Fault 1 Subcode Faults 2-43
545 Fault 2 Subcode Faults 2-43
547 Fault 3 Subcode Faults 2-43
549 Fault 4 Subcode Faults 2-43
551 Fault 5 Subcode Faults 2-43
553 Fault 6 Subcode Faults 2-43
555 Fault 7 Subcode Faults 2-43
557 Fault 8 Subcode Faults 2-43
595 Port Mask Act Security 2-48
596 Write Mask Cfg Security 2-48
597 Write Mask Act Security 2-49
598 Logic Mask Act Security 2-49
