Rockwell Automation 20C PowerFlex 700H Drives Programming - Manual (Page 40)

40 Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
Chapter 2 Programming and Parameters
U
TIL
IT
Y
Diagno
st
ic
s
215 [Last Stop Source]
Displays the source that initiated the most recent
stop sequence. It will be cleared (set to 0) during
the next start sequence.
Default:
Options: 0
1
2
3
4
5
6
7
8
9
10
11
12
13
Read Only
“Pwr Removed”
“DPI Port 1”
“DPI Port 2”
“DPI Port 3”
“DPI Port 4”
“DPI Port 5”
“Reserved”
“Digital In”
“Fault”
“Not Enabled”
“Sleep”
“Jog”
“Autotune”
“Precharge”
361
362
363
364
365
366
216 [Dig In Status]
Status of the digital inputs.
1 = Input Present
0 = Input Not Present
Read Only 361
thru
366
217 [Dig Out Status]
Status of the digital outputs.
1 = Output Energized
0 = Output De-energized
Read Only 380
384
388
thru
380
384
388
218 [Drive Temp]
Present operating temperature of the drive power
section.
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
220 [Motor OL Count]
Accumulated percentage of motor overload.
Continuously operating the motor over 100% of
the motor overload setting will increase this value
to 100% and cause a drive fault.
Default:
Min/Max:
Units:
Read Only
0.0/100.0%
0.1%
047
048
224 [Fault Frequency]
Captures and displays the output speed of the
drive at the time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/+[Maximum Freq]
0.1 Hz
079
225
thru
230
225 [Fault Amps]
Captures and displays motor amps at the time of
the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/[Rated Amps]
×
2
0.1 Amps
224
thru
230
226 [Fault Bus Volts]
Captures and displays the DC bus voltage of the
drive at the time of the last fault.
Default:
Min/Max:
Units:
Read Only
0.0/Max Bus Volts
0.1 VDC
224
thru
230
Fil
e
Gr
oup
No
.
Parameter Name & Description Values Rela
ted
Name Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Dig
ita
l In
6
Dig
ita
l In
5
Dig
ita
l In
4
Dig
ita
l In
3
Dig
ita
l In
2
Dig
ita
l In
1
Default x x x x x x x x x x 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
Name Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
D
igital Out3
D
igital Out2
D
igital Out1
Default x x x x x x x x x x x x x 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
