046 [Mtr NP Pwr Units]
Selects the motor power units to be used.
“Convert HP” = converts all power units to
Horsepower.
“Convert kW” = converts all power units to
kilowatts.
Note: This parameter does not get changed with a
“Reset to Defaults”.
Default:
Options:
–
0
1
2
3
Based on Drive Rating
“Horsepower”
“kiloWatts”
“Convert HP”
“Convert kW”
047 [Motor OL Hertz]
Selects the output frequency below which the
motor operating current is derated. The motor
thermal overload will generate a fault at lower
levels of current below this output frequency.
Default:
Min/Max:
Units:
Motor NP Hz/3
0.0/Motor NP Hz
0.1 Hz
042
220
048 [Motor OL Factor]
Sets the operating level for the motor overload.
Default:
Min/Max:
Units:
1.00
0.20/2.00
0.01
042
220
049 [Motor Poles]
Defines the number of poles in the motor.
Note: Maximum value changed from 12 to 18 for
firmware revision 4.001.
Default:
Min/Max:
Units:
4
2/18
1 Pole
050 [Motor OL Mode]
“Pwr Cyc Ret” - If “0”, the value of parameter 220 [Motor OL Count] is reset to zero by a drive reset
or power cycle. If “1”, the value of parameter 220 [Motor OL Count] is maintained. A “1” to “0”
transition resets parameter 220 [Motor OL Count] to zero.
Note: Added for firmware revision 3.001.
1 = Enabled
0 = Disabled
220
To
rq
A
tt
ribu
tes
053 [Motor Cntl Sel]
Sets the method of motor control used in the
drive.
Default:
Options:
0
0
1
2
3
“Sensrls Vect”
“Sensrls Vect”
“SV Economize”
“Custom V/Hz”
“Fan/Pmp V/Hz”
055 [Maximum Freq]
Sets the highest frequency the drive will output.
Refer to parameter 083 [Overspeed Limit].
Default:
Min/Max:
Units:
Based on Drive Rating
5.0/320.0 Hz
0.1 Hz
083
056 [Compensation]
“Mtr Lead Rev” - If “1”, reverses the phase rotation of the applied voltage, effectively reversing
the motor leads.
Notes: Not retained when the parameters are reset to defaults. Added for firmware revision
3.001.
1 = Enabled
0 = Disabled
