Chapter 2
Programming and Parameters
This table is an example of how each parameter type is presented in this manual.
Each numbered column is described in the table following this example.
Column
No.
Description
1
File – Lists the major parameter file category.
2
Group – Lists the parameter group within a file.
3
No. – Parameter number.
= Parameter value cannot be changed until drive is stopped.
= 32 bit parameter.
4
Parameter Name & Description – Parameter name as it appears on an LCD HIM, with a brief description of
the parameters function. Parameters names appear within square brackets [] throughout this manual.
5
Values – Defines the various operating characteristics of the parameter. Three types exist.
ENUM
Default:
Options:
Lists the default value assigned at the factory. “Read Only” = no default.
Displays the optional programming selections available.
Bit
Bit:
Lists the bit name, default setting and place holder for each bit.
Numeric
Default:
Min/Max:
Units:
Lists the default value assigned at the factory. “Read Only” = no default.
The range (lowest and highest setting) possible for the parameter.
Unit of measure and resolution as shown on the LCD HIM.
Important: Some parameters will have two unit values:
• Analog inputs can be set for current or voltage with parameter 320 [Anlg In Config].
• Setting parameter 79 [Speed Units] selects “Hz” or “RPM.”
Important: When sending values through DPI ports, simply remove the decimal point to arrive
at the correct value (i.e. to send “5.00 Hz,” use “500”).
6
Related – Lists parameters (if any) that interact with the selected parameter. The symbol “
” indicates
that additional parameter configuration information is available in
1
2
3
4
5
6
Fi
le
Grou
p
No
.
Parameter Name & Description
Values
Rela
te
d
UTILIT
Y
Driv
e . . .
198
[Load Frm Usr Set]
Loads a previously saved set of parameter values
from a selected user set location in drive
nonvolatile memory to active drive memory.
Default:
Options:
0
0
1
2
3
“Ready”
“Ready”
“User Set 1”
“User Set 2”
“User Set 3”
199
Di
ag
n
os
ti
cs
216
[Dig In Status]
Status of the digital inputs.
Read Only
361
thru
366
MO
TO
R . .
.
M
otor
D
ata 044
[Motor NP RPM]
Set to the motor nameplate rated RPM.
Default:
Min/Max:
Units:
1750.0 RPM
60.0/19200.0 RPM
1.0 RPM
Name
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Re
se
rv
ed
Di
gi
ta
l In
6
Di
gi
ta
l In
5
Di
gi
ta
l In
4
Di
gi
ta
l In
3
Di
gi
ta
l In
2
Di
gi
ta
l In
1
