Rockwell Automation 20C PowerFlex 700H Drives Programming User Manual
Page 53
Rockwell Automation Publication 20C-PM001F-EN-P - March 2012
53
Programming and Parameters
Chapter 2
INPUTS/OUT
PUT
S
Digi
tal In
put
s
361
362
363
364
365
366
[Digital In1 Sel]
[Digital In2 Sel]
[Digital In3 Sel]
[Digital In4 Sel]
[Digital In5 Sel]
[Digital In6 Sel]
(9)
Selects the function for the digital inputs.
Notes: Options 36…42 are “Reserved”. Added
options 43 and 46 for firmware revision 3.001.
Added options 41, 42, 44 and 45 for firmware
revision 4.001. Added option 68 for firmware
revision 5.002.
(1)
Speed Select Inputs.
To access Preset Speed 1, set [Speed Ref x Sel] to
“Preset Speed 1”.
Type 2 Alarms - Some digital input programming
may cause conflicts that will result in a Type 2
alarm. Example: [Digital In1 Sel] set to “5, Start” in
3-wire control and [Digital In2 Sel] set to 7 “Run”
in2-wire.
Refer to
for information on
resolving this type of conflict.
(2)
When [Digital Inx Sel] is set to option 2 “Clear
Faults” the Stop button cannot be used to clear a
fault condition.
(3)
Typical 3-Wire Inputs - Requires that only 3-wire
functions are chosen. Including 2-wire selections
will cause a type 2 alarm.
(4)
Typical 2-Wire Inputs - Requires that only 2-wire
functions are chosen. Including 3-wire selections
will cause a type 2 alarm. See
for conflicts.
(5)
Auto/Manual - Refer to the Installation Manual for
details.
(6)
Opening an “Enable” input will cause the motor to
coast-to-stop, ignoring any programmed Stop
modes.
Default:
Default:
Default:
Default:
Default:
Default:
Options:
4
5
18
15
16
17
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30-33
34
35
36-40
41
42
43
44
45
46
68
“Stop – CF”
“Start”
“Auto/ Manual”
“Speed Sel 1”
“Speed Sel 2”
“Speed Sel 3”
“Not Used”
“Enable”
(6)(8)
“Clear Faults”(CF)
(2)
“Aux Fault”
“Stop – CF”
(8)
“Start”
(3)(7)
“Fwd/ Reverse”
(3)
“Run”
(4)(8)
“Run Forward”
(4)
“Run Reverse”
(4)
“Jog1”
(3)
“Jog Forward”
(4)
“Jog Reverse”
(4)
“Stop Mode B”
“Bus Reg Md B”
“Speed Sel 1”
(1)
“Speed Sel 2”
(1)
“Speed Sel 3”
(1)
“Auto/ Manual”
(5)
“Local”
“Acc2 & Dec2”
“Accel 2”
“Decel 2”
“MOP Inc”
(10)
“MOP Dec”
(10)
“Excl Link”
(10)
“PI Enable”
“PI Hold”
“PI Reset”
“Pwr Loss Lvl”
Reserved
“Jog 2”
“PI Invert”
“Reserved”
“UserSet Sel1”
(10)
“UserSet Sel2”
(10)
“Run Level”
(11)
“RunFwd Level”
(11)
“RunRev Level”
(11)
“Run w/Comm”
(11)
“Manual/Auto”
(12)
100
156
162
096
141
143
195
194
124
(7)
A “Dig In ConflictB” alarm will occur if a “Start” input is programmed without a “Stop” input.
(8)
Refer to the Sleep Wake Mode Attention statement on
page 33
.
(9)
A dedicated hardware enable input is available via a jumper selection. Refer to Installation Manual for
further information.
(10)
Refer to [Dyn UsrSet Sel] on
page 37
for selection information.
(11)
Refer to
Selected Option Definitions – [Analog Outx Sel], [Digital Inx Sel], [Digital Outx Sel] on page 55
.
(12)
The function of this value is similar to 18 “Auto/Manual”, except the polarity is opposite.
Fil
e
Gr
oup
No
.
Parameter Name & Description
Values
Rela
ted
3
2
1
Auto Reference Source
0
0
0
0
1
1
1
1
0
0
1
1
0
0
1
1
0
1
0
1
0
1
0
1
Reference A
Reference B
Preset Speed 2
Preset Speed 3
Preset Speed 4
Preset Speed 5
Preset Speed 6
Preset Speed 7
