[ Care and Use ManUal ]
Sep-Pak Cartridges and Plates 5
Table 4: Accessories and Spare Parts for the Waters Extraction Manifolds
Description Qty. Part No.
Needle valves(required when using
silica-based SPE cartridges) 20/pk WAT200685
Needle 20/pk WAT200691
C over, 20 position without gauge assembl y 1 WAT20068 6
Gauge assembly, Vacuum 1 WAT200687
Reservoir, glass with outlet valv e 1 WAT200688
O utlet valve kit 1 WAT200689
Gasket for cove r 1 WAT200690
Ejector tool 1 WAT058839
Luer plugs 25/pk WAT058851
Rubber ball ring (for vacuum gauge assembly) 1 WAT058840
Reversible vial rack for 1 mL or 4 mL
Autosampler vials 1 WAT058871
13 x 75 mm test tube rack 1 WAT200678
13 x 100 mm test tube rack 1 WAT200679
16 x 75 mm test tube rack 1 WAT200680
16 x 100 mm test tube rack 1 WAT200681
Reservoir, 30 cc (for Sep-Pak Plus, Light,
Vac & Classic cartridges) 48/pk WAT011390
Reservoir, 60 cc
(for Sep-Pak Plus, Light & Vac cartridges) 12/pk WAT024659
Adapter, male-male Luer
(for Sep-Pak Classic cartridges) 100/pk WAT024310
Adapter (to attach reservoir to 1, 3 & 6 cc
Sep-Pak Vac cartridges) 12/pk WAT054260
Adapter (to attach reservoir to 12, 20 & 35 cc
Sep-Pak Vac cartridges) 10/pk WAT048160
Vacuum pump (110 V, 60 Hz) 1 WAT085114
Vacuum pump (220 V, 50 Hz) 1 WAT085115
VI. AddItIonAL InForMAtIon
Sep-Pak accessories are available to help with your solid-phase extraction.
Ordering information for these products is given below.
For more detailed information, consult the Chromatography Columns
and Supplies Catalog by visiting www.waters.com (literature code:
720002419EN), or contact your Waters representative.
If you require technical assistance, or have any questions regarding sample
preparation, visit www.waters.com or call us at 1-800-252-4752.
Table 2: Sep-Pak Cartridge Accessories
Table 3: Extraction Manifolds (Includes 20 needle tips, 25 plugs and
ejector tool)
Description Qty. Part No.
30 cc Reservoir 48/pk WAT011390
60 cc Reservoir 12/pk WAT024659
Reservoir adapters for 1, 3 and 6 cc VAC 12/pk WAT054260
Reservoir adapters for 12, 20 and 35 cc VAC 10/pk WAT048160
Male-male adapter 100/pk WAT024310
Male luer plugs 100/pk WAT044395
Female luer plugs 100/pk WAT044385
Sep-Pak connections kit 1 WAT011400
Description Part No.
20 position extraction manifold without rack WAT200677
20 position extraction manifold with
13 x 75 mm test tube rack WAT200606
20 position extraction manifold with
13 x 100 mm test tube WAT200607
20 position extraction manifold with
16 x 75 mm test tube rack WAT200608
20 position extraction manifold with
16 x 100 mm test tube WAT200609
