REPAIR PARTS
Ref
Part
Number Description Qty
Serial
Number
1 130802 SUPPORT – LH WELDT 1
2 130803 SUPPORT – RH WELDT 1
3 159590 SPACER BRACKET 2
4 130831 SUPPORT – RH WELDT 1
5 130817 SUPPORT – LH WELDT 1
6 REF See 6.5 Cover and Supports, page 113 .
7 REF See 6.3 Lower Roll and Frame Assembly, page 109 .
A 50190 BOLT – HH (MIN THD) 5/8 NC X 7.5 LG GR 5 ZP
B 50225 NUT – FLANGE DT SMOOTH FACE .625-11UNC
C 21471 BOLT – RHSN 1/2 NC X 1.25 GR 5 ZP
D 50186 NUT – FLANGE LOCK SM FACE DT 0.500-13UNC GR5
E 18523 BOLT – RHSN 5/8 NC X 1.5 GR 5 ZP
169254
136
Rev. D
