REPAIR PARTS
Ref
Part
Number Description Qty
Serial
Number
1 159432 PAN- – FINGER FEED WELDT 1
2 159399 FRAME, FEED DECK – WELDT 1
3 133838 ROLLER – DRIVE 4", WELDT 1
4 49306 FLANGE 1
5 21859 BEARING – SPH OD EXT INNER RACE 1 3/16 BORE 1
6 30661 FLANGE 1
7 159197 MOTOR – HYD 4.0 CID (WITH 921 PSI RELIEF) 1
37181 SEAL KIT – FOR MOTOR 159197
159606 VALVE – RELIEF, 921 PSI
8 159183 HOLDER – COUPLING 1
9 103738 CLAMP – PVC INSULATED 13/16 " TUBE SIZE 1
10 21801 FITTING – ELBOW 90° HYD 1
11 130998 HOSE 1
12 30314 FITTING – ELBOW 90° HYD 1
13 135213 COUPLING – FEMALE HYD. 3/8 FLAT FACE BULKHEAD 1
135481 SEAL KIT – FOR 3/8 FEMALE COUPLER
14 21881 FITTING – ADAPTER HYD 1
15 159422 HOSE 1
16 30819 FTG – 1/2" HYD UNION 1
17 44209 O-RING 1
18 135386 COUPLER – MALE HYD. 3/8 IN. FLAT FACE 1
111978 SEAL KIT – FOR 3/8 MALE COUPLER
19 159256 SHAFT – IDLER ROLLER 1
20 133124 HOUSING ASSY – RH IDLER CUP (includes items 22–24) 1
21 133126 HOUSING ASSY – LH IDLER CUP (includes items 22–24) 1
22 100862 SEAL – OIL 4
23 118185 BEARING – BALL CYL, 52 MM O.D., 25 MM I.D. 2
24 118011 RING – RETAINING INTERNAL 2
25 133372 CAP, DUST 2
26 21010 FTG – LUBE 90 DEG 1/4 - 28 TAPER THD 2
27 159383 SUPPORT WELDT – LH 1
28 159385 SUPPORT WELDT – RH 1
29 159260 GUIDE – LH 1
169254
132
Rev. D
