REPAIR PARTS
Ref
Part
Number Description Qty
Serial
Number
1 159204 COVER WELDT 1
2 159206 SUPPORT – STRUT LH 1
3 159207 SUPPORT – STRUT RH 1
4 135001 BOLT – SHOULDER .375-16UNC 2
5 42592 WASHER – FLAT 8
6 42045 WASHER – RUBBER 4
7 149317 HANDLE 4
8 159294 STRAP – RUBBER 2
9 16652 WASHER – FLAT 2
10 159220 DEFLECTOR WELDT, LH 1
11 130911 DEFLECTOR WELDT, RH 1
12 130905 DEFLECTOR – FIN LH 1
13 130906 DEFLECTOR – FIN RH 1
14 130548 DEFLECTOR – FIN 4
15 130900 BAFFLE 1
16 159598 SUPPORT – HANGER (TRACTOR MOUNTED) 1
17 159325 SUPPORT – KEEPER 1
18 13125 PIN – HAIR 2
19 18600 WASHER – FLAT, 21/32 ID X 1 5/16 IN OD ZP 2
A 21863 BOLT – RHSSN 3/8 NC X 0.75 LG GR 5 ZP
B 30228 NUT – FLANGE DT SMOOTH FACE 0.375-16UNC
C 21469 BOLT – RHSN 1/2 NC X 1.5 LG GR 5 ZP
D 19966 BOLT – RHSN 3/8 NC X 1.25 LG GR 5 ZP
E 21406 BOLT – HH 5/8 NC X 3.5 GR 5 ZP
F 50225 NUT – FLANGE DT SMOOTH FACE .625-11UNC
G 19965 BOLT – RHSN 3/8 NC X 1.0 GR 5 ZP
169254
130
Rev. D
