58
Sound Level Meter
5 I/O - Level 1
Setup the level for the control of e.g. the external Digital
I/O Adapter Box.
Select the • level field with the rotary wheel .
Press enter • and select the level for the control of the
external Digital I/O Adapter Box..
6 Selected Sound Level Values
To set the level values for the control of the external Digital
I/O Box.
Select the Out 1, Out 2, Out 3 or Out 4 • level with the ro-
tary wheel and press enter .
Set the level value with the rotary wheel
• and confirm
with enter .
7 I/O - Level 2
Follow the setting for I/O Sound Level 1. The I/O level 1 may
be combined with I/O level 2 using and/or combinations,
providing indications in level ranges. Alternatively, other lev-
els can be selected for the control of the external Digital I/O
Adapter Box.
8 LED - Level 2
Follow the setting for LED - Level 1.
I/O Box Limits with Triggered Events
If triggered-event recording is enabled, the digi-
tal output 4 (OUT4) is utilized as confirmation
feedback to the XL2 Input Keypad, thus the set-
ting is disabled.
