47
Sound Level Meter
4 Log Audio
The XL2 logs audio data as a wav-file. Choose among the
following settings:
Off Audio logging is off
On Audio logging is activate from mea-
surement start to stop.
Events Only Audio logging of triggered events
only.
For more details read the chapters Wav-File Recording and
Events.
5 Format
Choose among the following audio recording settings:
Compressed Compressed audio logging
Compressed+AGC Compressed audio logging with
automated gain control
24Bit_48kHz Linear audio logging in 24 bit,
48 kHz resolution (optional with
Extended Acoustic Pack)
6 Log Value Setting
Choose between the following settings:
ALL Logs all available sound pressure levels with-
out correction values.
Selected Logs a subset of up to 10 different sound
pressure levels, including correction values if
you require.
Select • Log Values with the rotary wheel .
Press enter • to toggle between All and Selected.
7 Selected Log Values
By setting Selected at 5 up to 10 individual log values can
be chosen.
Select the first value • Lxx with the rotary wheel and
press enter .

The pop-up window for level selection shows up.
Select the logging level with the rotary wheel • and con-
firm with enter .
At 100ms Logging is the log value selection limited to five
different parameters.
