155
Capture + Tolerances
#Hide
UnusedBands This parameter defines which tolerance fre-
quency range is shown. (not mandatory)
True Measurement results of fre-
quency bands without any
specified tolerance are not dis-
played.
False The measurement result of all
frequency bands are shown.
#nAllowed
Violations Allows a PASSED result with a maximum
number of n failed frequency bands (not man-
datory)
#FreqScale
Spacing Defines the frequency scale spacing in the X-
axis for the tolerance data. (not mandatory)
lin Tolerance data displayed with
linear frequency spacing, e.g.
used in the FFT function. (de-
fault setting)
log Tolerance data displayed with
logarithmic frequency spacing
e.g. used in the 1/12 Oct + Tol
function.
#AutoStart Enables auto start function. (not mandatory)
True Auto start is active. The run indi-
cation displays A. The measure-
ment starts automatically after
the trigger level is reached.
Alternatively the measurement
may start manually by pressing
start
.
False No auto start function. (default
setting)
