© Metal Sales Manufacturing Corporation / Subject to change without notice, effective 02/09.
53
ARCHITECTURAL INSIDE CORNER DETAILS
SOFFIT INSIDE CORNER
Pancake Head Woodscrew (1'-0" o.c.)
Double Bead Tape Sealant
Inside Corner
6RI¿W 3DQHO
Pop-Rivet (1'-0" o.c.)
Moisture Barrier (by others)
1" Z-Closure
ARCHITECTURAL PANEL INSIDE CORNER
Inside Corner
Double Bead Tape Sealant
Pancake Head Woodscrew (1'-0" o.c.)
Pop-Rivet (1'-0" o.c.)
Double Bead Tape Sealant
Z-Closure
Architectural Panel
