© Metal Sales Manufacturing Corporation / Subject to change without notice, effective 02/09.
33
ARCHITECTURAL IMAGE II INSTALLATION (EXPOSED FASTENED END)
STEP
1
1RWH 0RLVWXUH %DUULHUV (DYH *XWWHU DQG 9DOOH\ ÀDVKLQJV PXVW ¿UVW EH LQVWDOOHG EHIRUH SDQHO
installation can begin (see pages 37-40).
Image II panels are installed from left to right or right to left.
1. Apply a row of Double Bead Tape Sealant on the top leg of the Eave Flashing.
,QVWDOO ¿UVW SDQHO VR WKDW WKH SDQHO HQG KDV SURSHU RYHUKDQJ UHIHU WR SDJHV PDNLQJ VXUH WKDW
panel is square to eave and rake. ,W LV FULWLFDO WKDW WKH ¿UVW SDQHO EH VWUDLJKW DQG VTXDUH ZLWK WKH
building as it controls alignment of the following roof panels.
)DVWHQ SDQHO WR VXEVWUDWH ZLWK [ 7UXVV +HDG :RRGVFUHZ LQ center of the fastening groove
located along the male leg of the panel. Fastener spacing must be designed to meet local building
codes (see page 23). It is important that the fastener be placed in the center of the fastening
groove and make sure not to over tighten screws.
)DVWHQ ,PDJH ,, SDQHO ZLWK [ :RRGVFUHZV WKURXJK 'RXEOH %HDG 7DSH 6HDODQW ÀDVKLQJ
and into the solid substrate as shown below.
1. Snap second panel in place making sure panel ends are aligned. Snap panel in place working from
one end to the other.
)DVWHQ ,PDJH ,, SDQHO ZLWK [ :RRGVFUHZV WKURXJK 'RXEOH %HDG 7DSH 6HDODQW ÀDVKLQJ
and into the solid substrate as shown below.
3. Continue with previous step until installation is complete.
)DVWHQ SDQHO WR VXEVWUDWH ZLWK [ 7UXVV +HDG :RRGVFUHZ LQ center of the fastening groove
located along the male leg of the panel. Fastener spacing must be designed to meet local building
codes (see page 23). It is important that the fastener be placed in the center of the fastening
groove and make sure not to over tighten screws.
2QFH LQVWDOODWLRQ LV FRPSOHWH ¿OO HDFK ORZHU HQG RI SDQHO ULE ZLWK 7XEH 6HDODQW DQG FOHDQ DQ\ GHEULV
and excess sealant before continuing next area.
STEP
2
INSTALLING FIRST PANEL
INSTALLING SECOND PANEL
Square panel to rake condition
#9-15 x 1" Woodscrew
Properly position panel for eave condition
Fasten in center of
panel slot / groove
with Truss Head
Woodscrew
#9-15 x 1" woodscrew into solid substrate
Apply sealant at all panel
rib ends along eave
Square panel to rake
Properly position panel keeping ends flush
Double Bead Tape Sealant
CAUTION
Additional screws
may be required for
high snow loading
and steep slopes.
CAUTION
Additional screws
may be required for
high snow loading
and steep slopes.
Double Bead Tape Sealant
