ARCHITECTURAL
SOFFIT PANEL INSTALLATION (
CONT
.)
FASTENING INFORMATION
Soffit panel can be installed in either direction.
INSTALLED PANEL CROSS SECTION
Fastening groove
Pancake Head Woodscrew
Factory applied mastic (optional)
Wood Substrate
