About this documentation
Terminology used (presented according to the order in the device view)
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
1.4 Terminology used (presented according to the order in the device view)
Term/abbreviation Position in the device view Function
Machine module tree
MMT
A10_MachineModuleTree
The "MachineModuleTree" (MMT) maps the
structure of the automation system in the form of
machine modules.
• In the "MachineModuleTree", all machine
modules required for the machine are
interconnected hierarchically according to the
mechatronic interaction.
ModuleApplicationCalls
MAC A11_ModuleAppCalls
The module applications are to be assigned to the
corresponding task within the
"ModuleApplicationCalls".
• Thus it is defined which module application is to
be processed within the individual tasks.
Machine module
MM
A70_MachineModuleSources
A machine module maps a unit of the real machine
structure in the »PLC Designer«.
• The machine module is part of the
MachineModuleTree(MMT) within which the
individual machine modules are
interconnected.
Machine module
application
ModApp/MAP
The machine module application provides the
functionality of a machine module.
• A machine module can contain one or several
machine module applications.
Machine function block
MFB
The machine function block represents the
machine module in the machine module tree
(MMT).
