9
ENGLISH
6.2. DB1 Initial Setup
When the DB1 enters setup mode it will display the
setup Home Menu illustrated above.
The four menu items provide the following functions:
Display
By default, the display is set to go dim after 30
seconds of button inactivity to reduce visual distraction
in normal operation. Alternatively, it may be set to go
off altogether. As soon as a button is pressed, the
display becomes fully bright and is always bright in
setup mode.
On/Off
In this context,
Off refers to the Standby condition. The
function may be set to Manual, Auto(matic), or via the
Trigger 1 input. The default is Manual.
To fully disconnect the DB1 from mains
power, it is necessary to switch off the
mains outlet socket or withdraw the
mains plug.
If Manual is selected, the DB1 front panel standby
button or an RS232 home automation system must be
used to switch between on and off.
If Auto is selected the DB1 will switch on automatically
when an input audio signal is detected and off
following a specified time after the input signal stops.
The automatic switch-off delay time can be set in the
subsequent menu by pressing the button when
Auto
is highlighted. Accessing the delay time will also select
Auto as the switching method.
If Trigger 1 is selected, 12V at the Trigger 1 input will
switch the DB1 on and 0V will switch it off. To proceed
with DB1 setup, ensure that the On/Off parameter is
initially set to
Manual.
Trigger 2
Enables DB1 presets to be selected in turn by a
12V control signal on the Trigger 2 input. Selecting
In engages this control feature and selecting Out
disengages it.
Out should be selected if your DB1 is
integrated within an RS232 home automation system.
The default is
Out.
Pressing the button while In is highlighted sets
Trigger 2 as the switching mode and allows the user
to select which Presets correspond to 12V and 0V at
the
Trigger 2 input. If In is the selected mode, Preset
switching via the front panel buttons in normal mode is
then disabled. The default presets are Preset 1 for 0V
and Preset 2 for 12V.
Audio
The
Audio option in the setup home page provides
access to all the DB1 audio setup parameters. Select
Audio to move on to the next setup stage.
About
Displays the DB1 model number and internal software
version.
Setup
Display
Dim
On/Off
Manual
Trigger 2
Out
Audio
About
