Bowers & Wilkins DM100 User Manual
Dm100, Technical highlights
DM100
Stand-mount/Bookshelf loudspeaker system
Product Summary
●
The DM100 is a compact 2-way system created for small rooms.
●
Advanced technology was employed to actively reduce the number of components in the
crossover.
Technical highlights
●
Refinements in the enclosure give the DM series reduced in lower mid-band coloration and a
dramatic improvement in transient response.
●
Advanced optimisation techniques employing modal analysis of the cabinet structure were a
design feature of the enclosure in all four monitors.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
www.bwspeakers.com
Drive Units
Frequency Response
Sensitivity
1 x 26mm dome/coil construction of
special polymide material
1 x 150mm nominal piston dia and
26mm high temperature voice coil with
critically impregnated composite short
fibre cone
± 3dB 80Hz to 20kHz
89dB (2.83V, 1m)
Power Handling
Dimensions
Finish
10W – 75W
Height: 370mm Width: 220mm
Depth: 210mm
American Walnut or Black Ash vinyl
