Bowers & Wilkins DM330 - Manual

DM330
Stand-mount/Bookshelf loudspeaker system
Product Summary
● An irresistible combination of super sensitivity, high acoustical output – at low cost.
● Bouquets from hi-fi critics for the DM110/DM220 included this from Geoffrey Horn of
Gramophone “so I say to B&W how do you follow that?” with the DM330 – that’s how
Mr Horn!.
Technical highlights
● Refinements in the enclosure give the DM series reduced in lower mid-band coloration and a
dramatic improvement in transient response.
● Advanced optimisation techniques employing modal analyses of the cabinet structure were a
design feature of the enclosure in all four monitors.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
www.bwspeakers.com
Drive Units
Frequency Response
Sensitivity
1 x 26mm dome/coil construction of
special polymide material
2 x 200mm nominal piston dia and
26mm high temperature voice coil with
critically impregnated composite short
fibre cone
± 3dB 48Hz to 20kHz
91dB (2.83V, 1m)
Power Handling
Dimensions
Finish
10W – 100W
Height: 857mm Width: 290mm
Depth: 320mm
American Walnut or Black Ash vinyl
