DM560
Stand-mount/Bookshelf loudspeaker system
Product Summary
● The two way front vented system encompasses the same design technology of the DM550
with its rigid one-piece baffle construction, but offers a noticeable extended bass – thanks to
a bigger 8in bass/midrange driver and increased enclosure size.
Technical highlights
● B&W's Tweeter technology ensures that the sound remains focused and time sensitive and
that the stereo image is presented with unparalleled three dimensional accuracy.
● The cabinets feature a specially designed high density front baffle which achieves almost
Matrix-like stability in strengthening overall enclosure construction. The bevel edges of the front
moulding reduce diffraction and improve dispersion.
● The crossover components use heavy gauge wire throughout and new drivers guarantee not
only high reliability but ensure that top specifications are met.
B&W Loudspeakers Ltd reserves the right to amend details of the specifications without notice in line with technical developments. E & OE. All trademarks acknowledged.
www.bwspeakers.com
Drive Units
Frequency Response
1 x 26mm high-frequency with
aluminium dome, 26mm coil on
aluminium dome former, wound with
polymide resin and heat cured
1 x 200mm bass/midrange with
composite short fibre cone, 26mm coil
on high temperature former, wound with
polymide resin and heat cured
65Hz – 20kHz ± 2.5dB on reference
axis
Sensitivity
Nominal Impedance
Power Handling
Dimensions
Finish
90dB spl(2.83V 1m)
8 ohms
10W – 75W into 8 ohms on
unclipped programme
Height: 490mm Width: 236mm
Depth: 302mm
Black ash or walnut vinyl
