Communication manual 8400 motec CANopen
Product description
Connections and interfaces
18
L
EDS84DMOTCAN EN 3.0 - 11/2011
 By default, the CANopen connectors are already pre-assembled and wired with the
terminal strip X3.
 The CANopen connections and further connections (e.g. digital inputs) can be freely
designed at the positions A1 ... A4 and B1 ... B4..
 The connections can be equipped with 5-pole M12 connectors, or optionally with cable
glands (cable cross-section max. 1.0 mm 2 , AWG 18).
 The M12 connectors, cable glands and prefabricated system cables can be obtained
from various manufacturers.
 Wire the M12 connectors or cable glands used to the corresponding contacts of
terminal strips X3, X4, and X61.

"Inverter Drives 8400 motec" hardware manual
Observe the notes and wiring instructions given in the documentation.
