Communication manual 8400 motec CANopen
Product description
Product features and variants
3.2 Product features and variants
The CANopen communication unit is available in the following versions:
 The CANopen communication unit ...
– is mounted on the wiring unit (E84DGVNxx);
– is exclusively supplied internally by the drive unit (E84DGDVxxxxxxxx).
 The I/O connections can be led into the device via M12 connectors or by means of cable
glands.
 In the E84DGFCC9xx version, a maximum of four digital inputs is conducted on M12
connectors (see "Inverter Drives 8400 motec" hardware manual).
 Devices without an integrated safety system (safety option) have no analog input and
no relay output.
 In the case of the E84DGFCCxJx communication units, the integrated safety system can
be used for the protection of persons on machines.
 Setting of the CAN node address and baud rate is possible via DIP switch or code.
 Communication with the Lenze »Engineer« (access to all Lenze parameters) is
preferably carried out via the CAN bus. Furthermore communication can be effected via
the diagnostic interface of the drive unit.
Product series Type designation Features
Enclosure IP
65
CANop
en
M12 I/
O:
T
er
m
in
al
I/
O:
M1
2
Sa
fe
ty
Inverter Drives 8400 motec
CANopen communication unit
E84DGFCCANP z z z
E84DGFCC9NP z z z
E84DGFCCAJP z z z z
E84DGFCC9JP z z z z

"Inverter Drives 8400 motec" hardware manual
Here you'll find detailed information on the integrated safety system (safety
option).
Software manual / »Engineer« online help "Inverter Drives 8400 motec"
Here you will find detailed information on how to configure the safety system
(safety option).
