Index
122
Lenze · E94AYCPM communication module (PROFIBUS®) · Communication Manual · DMS 12.0 EN · 11/2012 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
I
ICM statistic counter (C13990) 101
ICM statistic counter (C14990) 110
Identification 12
Installation 21
Interface 15
Interfaces 14
Interruption 81
Interruption of internal communication 81
L
Layout of the safety instructions 9
LED status displays 82
M
Maximum 115
Maximum time per DPV1 parameter access (0x974) 115
Mechanical installation 22
Monitoring 78 , 80
Permanent interruption of PROFIBUS communication 78
Settings and displays in the »Engineer« 80
Short-time interruption of PROFIBUS communication 79
Monitoring time
Data exchange (C13881) 98
Data exchange (C14881) 107
Watchdog (C13882) 98
Watchdog (C14882) 107
Mounting 22
N
Nameplate 12
Network topology 15 , 23
Number of stations 15 , 24
O
Operating conditions 15
P
Parameter addressing 47
Parameter data transfer 47
Parameter reference 91
Parameters of the communication module for slot MXI1 93
Parameters of the communication module for slot MXI2 102
PDO mapping 44
PNO identification number 15
Process data objects 44
Process data transfer 44
Processing time 19
Product description 12
Profibus
Data_Exchange state exited (error message) 90
Error: Lenze setting loaded (error message) 89
Internal error (error message) 89
Internal mapping error (error message) 89
Invalid parameter record (error message) 89
Lost connection to 9400 base device (error message) 88
Memory
No access (error message) 88
Read error (error message) 88
Write error (error message) 88
Restart after watchdog reset (error message) 88
PROFIBUS connection 27
PROFIBUS error messages
Causes and remedies 88
Short overview 87
Profibus watchdog
DP-V1 MSAC2 elapsed (error message) 90
Monitoring time elapsed (error message) 90
PROFIdrive 57
PROFIdrive objects (DP-V1) 114
PROFIdrive parameter data channel (DP-V1) 57
PROFIsafe 77
Target address (C13897) 100
Target address (C14897) 109
Protection against uncontrolled restart 33
Protection of persons 11
Protective insulation 16
Protocol data 19
Q
Querying the bus status 84
Querying the current bus status 84
R
Reaction on communication fault (C13880) 97
Reaction on communication fault (C14880) 106
Reading parameter data from the controller (DP-V0) 50
Reading parameter data from the controller (DP-V1) 61
Residual hazards 11
Resp. to comm. error with MXI1 (C01501) 92
Resp. to comm. error with MXI2 (C01502) 92
Resp. to imp. device conf. (C00615) 91
Resp. to new module in MXI1 (C00636) 91
Resp. to new module in MXI2 (C00637) 92
