14 Parameter reference
14.3 Parameters of the communication module for slot MXI2
102
Lenze · E94AYCPM communication module (PROFIBUS®) · Communication Manual · DMS 12.0 EN · 11/2012 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
14.3 Parameters of the communication module for slot MXI2
This chapter lists the parameters of the E94AYCPM communication module (PROFIBUS) for slot
MXI2 of the Servo Drive 9400 in numerically ascending order.
C14231
C14489
C14531
C14789
C14850
Parameter | Name:
C14231 | Service code
Data type: UNSIGNED_64
Index: 10344
d
= 2868
h
This code is for device-internal use only and must not be overwritten by the user!
Parameter | Name:
C14489 | Service code
Data type: UNSIGNED_8
Index: 10086
d
= 2766
h
This code is for device-internal use only and must not be overwritten by the user!
Parameter | Name:
C14531 | Service code
Data type: UNSIGNED_64
Index: 10044
d
= 273C
h
This code is for device-internal use only and must not be overwritten by the user!
Parameter | Name:
C14789 | Service code
Data type: UNSIGNED_8
Index: 9786
d
= 263A
h
This code is for device-internal use only and must not be overwritten by the user!
Parameter | Name:
C14850 | All words to master
Data type: UNSIGNED_16
Index: 9725
d
= 25FD
h
Display of the process data words transferred from the communication module to the PROFIBUS master.
In the subcodes 1 ... 32, all process data words to the master are displayed. Only the configured process data words
are valid.
Display area
(min. value | unit | max. value)
0 65535
Subcodes Info
C14850/1
...
C14850/32
; Read access Write access CINH PLC-STOP No transfer PDO_MAP_RX PDO_MAP_TX COM MOT
