Technical data, Current characteristics – Lenze 8400 protec Manual User Manual
Page 55

Technical data
Current characteristics
l
55
EDS84DPS424 EN 5.0
Maximum output currents [A]
1)
at a fixed switching frequency and U
LN
= 400V
2 kHz
4 kHz
8 kHz
16 kHz
Type
I
aM02
I
aM2
I
aM04
I
aM4
I
aM08
I
aM8
I
aM016
I
aM16
E84Dxxxx7514
4.8
4.8
4.8
4.8
2.8
4.8
1.8
4.0
E84Dxxxx1524
5.9
7.8
5.9
7.8
4.1
7.8
2.5
6.4
E84Dxxxx3024
11.0
14.6
11.0
14.6
9.5
14.6
5.5
9.5
E84Dxxxx4024
14.3
19.0
13.8
19.0
9.5
17.1
5.7
9.5
E84DHxxx7524
16.0
32.0
16.0
32.0
17.0
30.0
10.7
21.3
Maximum output currents [A]
1)
at a fixed switching frequency and U
LN
= 500V
2 kHz
4 kHz
8 kHz
16 kHz
Type
I
aM02
I
aM2
I
aM04
I
aM4
I
aM08
I
aM8
I
aM016
I
aM16
E84Dxxxx7514
4.8
4.8
4.4
4.4
2.1
4.4
1.4
3.1
E84Dxxxx1524
5.9
7.8
5.9
7.2
3.2
7.2
1.9
3.4
E84Dxxxx3024
11.0
14.6
10.6
13.5
7.4
13.5
4.2
7.4
E84Dxxxx4024
14.3
19.0
10.7
17.6
7.3
13.4
4.3
7.3
E84DHxxx7524
16.0
25.6
12.8
25.6
13.6
24.0
8.5
17.1
1)
The shown values apply to the operation with ambient temperatures of up to +45°C for 2/4kHz and up to +40°C for
8/16kHz. For ambient temperatures between +40/45°C and +55°C, a derating from 2.5 %/K to the given values must
be observed.
