Braking operation
Operation with spring−applied brake
Introduction
l
156
EDS84DPS424 EN 5.0
9.3
Operation with spring−applied brake
9.3.1
Introduction
(
Stop!
The integrated brake control includes an electronic switch which can control a
motor holding brake.
Only motor holding brakes which comply with the permissible data mentioned
in the Technical Data may be connected to the integrated brake control. (If
necessary, the holding brake must be controlled without a brake control via a
digital output and a coupling relay.)
If the permissible values mentioned in the Technical Data are not observed:
ƒ
the brake control may be destroyed.
ƒ
a safe operation of the motor holding brake is not ensured.
Lenze three−phase AC motors and G−motion geared motors can be equipped with
spring−applied brakes (motor holding brakes). 8400 protec controllers have an integrated
motor brake control.
