Technical data
Rated data
Overview
4
l
47 EDS84DPS424 EN 5.0
Output data
Voltage Frequency Rated current [A] Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E84Dxxxx7514 0 ... 400/500 0 ... 1000 2.4/1.9 1.8/1.4 3
E84Dxxxx1524 0 ... 400/500 0 ... 1000 3.9/3.1 2.9/2.3 3
E84Dxxxx3024 0 ... 400/500 0 ... 1000 7.3/5.8 5.5/4.4 3
E84Dxxxx4024 0 ... 400/500 0 ... 1000 9.5/7.6 7.1/5.7 3
E84DHxxx7524 0 ... 400/500 0 ... 1000 16.0/12.8 12.0/9.6 3
 Ambient temperature during operation
Power losses
Power loss P
V
[W]
Type when operating with rated output current I
arated
when controller is inhibited
E84Dxxxx7514 66
27
E84Dxxxx1524 84
E84Dxxxx3024 127
E84Dxxxx4024 155
E84DHxxx7524 232
