Electrical installation − EMS version
Devices in a power range of 0.75 ... 4 kW (3/PE AC 400 V)
Example circuits
7
l
120 EDS84DPS424 EN 5.0
Inductive
M
3~
U
V
W
+
+
BRK1
T1 T2
T
h
+ -
" "
0
" "
6 4 1 2 3 X21
+ c 1 2 3 a 5
M
3~
U
V
W
+
+
T1 T2
T
h
BRK1
+ -
~ ~ S1 S2
GL1
1
E84Dx...
5 8 4 6 1 7 3 X21
+ 1 2 X20
+
X80 X43 X42 X41 X32 X31
+
1 11 2 3 4 12 + X10 1 11 2 3 4 12 + X11
+
-
+24 V
GND
U24
=
X46
X47
X48
X45
X81
X82
X34
BRW1
1 2 +
"
E84D x... F
2 DC
560 V
+ -
+UG
-UG
PE
+ -
2 DC
24 V
+
-
Power
Data
E84DWSP060_D
E84DFx... 8400 protec EMS controller, inductive system
X10: +UG, −UG, PE 560 V DC (mains voltage)
X10: +, − 24 V DC (motor holding brake)
X11 Mains voltage loop−through technique (optional)
X31 ... X32 Fieldbus communication
X34 CANopen master PLC
X41 ... X43 DIO
X45 ... X48 EMS: Further DIO
X80 SSI
X81/X82 EMS: RS485/422
M Motor
0 Motor connection system: Plug type Q8/0
1 Motor connection system: Plug type Modular
T
h
PTC thermistor (PTC) or thermal contact (NC contact)
BRK1 Spring−applied brake
GL1 Spring−applied brake control
BRW1 External brake resistor at the optional terminal X20
U24 Supply voltage 24 V internal
