Diagnostics
Display of operating data, diagnostics
Status display via controller LEDs
10
l
160 EDS84DPS424 EN 5.0
Status display: device
Pos. Colour State Description
DRV−RDY green
on Controller is ready
blinking Controller is enabled
ERR red
on System error
blinking Fault is active
off No fault
24V−S green
on 24 V voltage is ready
off 24−V voltage is not ready
Brake yellow
on Motor holding brake is controlled (released)
off Motor holding brake is not controlled (applied)
Status display: fieldbus interface
Pos. Colour State Description
BUS−RDY green
blinking Communication has been established
on Communication has been stopped
off Communication has not been initialised
BUS−ERR red
fast blinking
Communication error
for PROFINET: Node not recognised
blinking for PROFINET: Node recognition
on Communication error
Link−1
yellow
fast blinking
only for PROFINET: Communication is active, telegrams are
transmitted
blinking Initialisation
Link−2
off Communication is not active
Status display: Digital signals
Pos. Colour State Description
DI1 yellow
on DI1 = HIGH
off DI1 = LOW
DI2 yellow
on DI2 = HIGH
off DI2 = LOW
DI3/DO1 yellow
on DI3/DO1 = HIGH
off DI3/DO1 = LOW
DI4/DO2 yellow
on DI4/DO2 = HIGH
off DI4/DO2 = LOW
DI5 yellow
on DI5 = HIGH
off DI5 = LOW
DI6 yellow
on DI6 = HIGH
off DI6 = LOW
