Braking operation
Operation with spring−applied brake
Wiring
9
l
158 EDS84DPS424 EN 5.0
9.3.2 Wiring
5 8 4 6 1 7 3 X21
+
M
3~
U
V
W
+
+
BRK1
T1 T2
T
h
+ -
" "
0
E84DWSP055_A
" "
6 4 1 2 3 X21
+ c 1 2 3 a 5
M
3~
U
V
W
+
+
T1 T2
T
h
BRK1
+ -
~ ~ S1 S2
GL1
1
E84DWSP055_B
0 "Cold brake" or "Integrated brake rectifier" wiring "24 V DC"
Connection system of plug type Q8/0
1 "Fast switch" wiring, connection system plug type Modular
X21 Motor connection
BRK1 Spring−applied brake
GL1 Spring−applied brake control
T
h
PTC thermistor (PTC) or thermal contact (NC contact)
M Motor
" HF−shield termination by large surface connection to PE.
+ Earthing
