Technical data
Rated data
Overview
4
l
46 EDS84DPS424 EN 5.0
4.2 Rated data
4.2.1 Overview
Basis of the data
Mains Voltage Voltage range Frequency range
U
Lrated
[V] U
Lrated
[V] f [Hz]
3/PE AC 400 320 − 0 % ... 440 + 0 % 45 − 0 % ... 65 + 0 %
3/PE AC 500 400 − 0 % ... 550 + 0 % 45 − 0 % ... 65 + 0 %
Output switching frequency f = 4 kHz
Input data
Voltage Frequency Rated current [A] Number of
phases
[V] [Hz] up to +45 °C  up to +55 °C 
E84Dxxxx7514 400/500 50/60 4.1/3.2 3.0/2.4 3
E84Dxxxx1524 400/500 50/60 5.5/4.4 3.5/3.1 3
E84Dxxxx3024 400/500 50/60 9.7/7.9 7.3/6.0 3
E84Dxxxx4024 400/500 50/60 12.9/11.0 9.5/8.1 3
E84DHxxx7524 400/500 50/60 20.8/16.6 15.6/12.5 3
 Ambient temperature during operation
Rated data of the 24−V buffer voltage (preserves the control functionality in the event of
a mains failure):
Supply voltage for control electronics of the controller
(safely separated power supply unit SELV/PELV)
Typ Voltage range U
DC
[V DC] Current consumption at + 24 V DC [A]
Min. 1) Max. 2)
E84Dxxxx7514
+ 24
(+19.2 − 0 % ... +28.8 + 0 %)
0.2 ... 0.6 2
E84Dxxxx1524
E84Dxxxx3024
E84Dxxxx4024
E84DHxxx7524
1) according to optional equipment, digital inputs and outputs are not wired
2) digital inputs and outputs are completely wired
)
Note!
The maximum total current of the 24 V voltage supply for external actuators
and encoders is 1 A, e.g. ports
ƒ Digital inputs/outputs at X4x,
ƒ Analog input at X50 or SSI at X80, and
ƒ Serial interfaces RS485/RS422 at X81/X82.
