7 Remote maintenance and diagnostics
7.2 Remote maintenance with a separate remote PC
56
Lenze · Controller-based Automation · System Manual · DMS 1.4 EN · 04/2014 · TD17
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
7.2 Remote maintenance with a separate remote PC
[7-1] Sample configuration: Remote maintenance of a Controller 3200 C
• The Engineering PC accesses the separate remote PC via an internet connection.
• The remote PC is connected to the controller via Ethernet.
• On the remote PC, the Lenze engineering tools (such as »EASY Starter«, »PLC Designer«) are
installed.
• The remote PC can be controlled from the Engineering PC via screen redirection.  »Virtual
Network Computing (VNC)«: Redirecting screen contents/entries ( 59)
The screen content of the controller are redirected to the remote PC. This makes it possible to
actuate the functions of the controller, for instance the same programs as for the local connection
via Ethernet can be used.
A basic overview of the different dial-in programs can be found in the following section.

Note!
Setting a remote maintenance may endanger the IT safety!
• This is particularly relevant if the remote PC is connected to an Ethernet network.
• Contact your IT administrator to take the necessary safety measures.
