4 System components
4.3 Controller: The control centre of the Controller-based Automation
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
Panel Controller
1) In preparation
2) Only the CAN master functionality is supported.
Area Panel Controller
p300 p500
Screen
Diagonal
measurement
10.9 cm
(4.3")
17.8 cm
(7.0")
26.4 cm
(10.4")
17.8 cm
(7.0")
26.4 cm
(10.4")
38.1 cm
(15.0")
Resolution [pixel] 480 x 272
(PSP)
800 x 480
(WVGA)
800 x 600
(SVGA)
800 x 480
(WVGA)
800 x 600
(SVGA)
1024 x 768
(XGA)
Touchscreen Resistive single touch
Anti-Newton ring design
Surface hardness 3H
Transmission factor ~80 %
Resistive single touch
Anti-Newton ring design
Surface hardness 3H
Transmission factor ~80 %
Processor type
Fanless
Cortex™-A8
800 MHz
ATOM™
1.6 GHz
Memory
RAM
512 MB
DDR3-RAM
1 GB
DDR2-RAM
Fixed memory (flash) 2 GB 2 GB
SD/SDHC card  128 MB  128 MB
Interfaces
SD/SDHC card
1 1
Ethernet 1 2
EtherCAT 1 1) 1
CANopen 1 2) -
USB 2.0 1 2
Option
(MC cards)
- CANopen
PROFIBUS master/slave
PROFINET device
Control/display elements
Reset pushbutton
 
Diagnostic LEDs 4 4
Operating system
Windows® Embedded Compact 7 Windows® CE 6.0
Size of retain memory
128 kB 1024 kB
Runtime software
Logic
 
Motion - 
Visu VisiWinNET® Compact CE, 500 Power Tags VisiWinNET® Compact CE, 1000 Power Tags
