4 System components
4.1 Engineering tools
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
4.1.4 »Engineer« (parameter setting, configuration, diagnostics)
Lenze applications for reuse
 Application templates and sample projects ( 22)
You need the »Engineer«for parameterising, configuring and diagnosing:
• I/O system 1000
• Servo Drives 9400 HighLine
• Inverter Drives 8400 StateLine/HighLine/TopLine
• Inverter Drives 8400 motec/protec
• Fieldbus modules (communication modules)
Functions in the »Engineer«:
• Editing/interconnecting function blocks,
• Configuring/interconnecting networks,
• Editing cams.
• Guided commissioning of the Inverter Drives 8400 (commissioning wizard)
The supported Lenze devices are accessed via:
 Online connection via the gateway function of the controller via CAN/
EtherCAT ( 48)
 Direct connection ( 50)
