System components

4.1

Engineering tools

Lenze · Controller-based Automation · System Manual · DMS 1.4 EN · 04/2014 · TD17

_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _

4.1.7

»VisiWinNET®« (visualisation)

»VisiWinNET®« Smart
»VisiWinNET®« Smart is a free-of-charge visualisation system...

• for the creation of simple visualisation/user interfaces;
• for diagnostic/service purposes;
• contains visualisation templates;
• can be combined with »VisiWinNET®« Professional.

»VisiWinNET®« Professional
»VisiWinNET®« Professional serves to create comprehensive visualisation/user interfaces of high

functionality and is integrated in the Microsoft® Visual Studio .NET development environment.
»VisiWinNET®« Professional...

• is suitable for visualisation and client/server SCADA systems;
• enables programming with Visual Basic, .NET and C# for implementing individual/company-

specific automation solutions;

• enables the use of visualisation templates and modules via "Drag&Drop";
• enables the connection to databases and Microsoft Office programs;
• Is suitable for the use of extensive report functions.

The supported Lenze devices are accessed via:



Online connection via the gateway function of the controller via CAN/EtherCAT

»VisiWinNET®« is a Lenze engineering tool for visualising Lenze automation

systems.

• »VisiWinNET®« serves to create visualisation and user interfaces for the

Lenze automation system.

• »VisiWinNET®« consists of the Engineering tool on the Engineering PC and
