4.1.3 »PLC Designer« (programming, parameter setting, diagnostics)
Lenze applications for reuse
 Application templates and sample projects ( 22)
The »PLC Designer« is required to...
• create the PLC (control) program of the Controller;
• transmit the PLC projects to the Controller;
• set parameters of/diagnose the Servo Inverter i700;
• configure the bus systems (EtherCAT, CANopen, PROFIBUS, PROFINET).
Basic functions:
• Graphic DIN 66025 Editor (G code) with DXF import
• Programmer of "Logic & Motion" according to IEC 61131-3:
• Instruction list (IL),
• Ladder diagram (LD),
• Function block diagram (FBD),
• Structured text (ST),
• Sequential function chart (SFC),
• Function block diagram (CFC).
• NC module library
• Cam editor
• Certified function blocks according to PLCopen part 1 + 2
