6 Commissioning of the system: standard procedure
_ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _
6 Commissioning of the system: standard procedure
In this chapter you'll learn which basic steps you have to carry out to commission a Lenze
automation system with a controller. The overview in the table shows which Engineering tool is
required in the corresponding commissioning step.

Online help/software manual of the engineering tool
Here, further information on the use can be found.

Detailed information on the single commissioning steps can be found in the
communication manuals:
• Controller-based Automation EtherCAT®
• Controller-based Automation CANopen®
• Controller-based Automation PROFIBUS®
• Controller-based Automation PROFINET®
What would you like to do? Description Which Lenze Engineering tool?
»EASY
Starter«
»Enginee
r«
»PLC
Designer
«
V3.x
»VisiWin
NET«
Planning/installing the
network of the automation
system
(Examples: Wiring the
devices, setting the DIP
switches)
• Preparation/wiring of the field
devices so that they can
communicate with the controller
(communication via controller-
internal gateway).
• Notes regarding preparations
required for the respective bus
systems can be found in the online
help for the »PLC Designer«/
»Engineer«.
None
Controller
commissioning
• Commissioning of the controller.
• Establishment of an online
connection to the controller

From V1.2
SP1
-  -
»WebConfig« via web browser
Configuration of...
• ...the controller,
• ...the bus system,
Parameterisation of the i700 servo
inverter
Program the controller
• Loading data to the controller.
• Transferring/starting the PLC
control program (must be compiled
without errors) to/in the controller.
- -  -
