85
6 Configuration
6.9 Web server
The integrated Web server provides you with convenient access via LAN to process values and
the event list of the system from a PC (Web browser). Access can be protected by a password.
There is a maximum of 1 MB memory for HTML pages available in the central processing unit.
The start page index.htm is available by default; access with the Web browser is performed by
entering the IP address of the central processing unit.
Further information can be found in the interface description B 705001.2.0.
Setup dialog
Function of buttons
NOTE!
This function requires the Microsoft Silverlight
1
plug-in. A message appears in the Web
browser if the plug-in is missing. At that point the installation of the plug-in becomes available.
1
Microsoft and Silverlight are registered trademarks of Microsoft Corporation.
Button Designation Description
Import Web Select the folder that contains the files required for the Web
application (incl. HTML files).
Export Web Select the folder to which the files used for the Web applica-
tion should be exported.
Delete Web After answering the security request, all files (except
index.htm) are removed from the setup file.
HTML tags HTML tags are used to convert names of variables into
addresses for Web server programming.
Security User name, password, and timeout time are specified here.
?
?
