3.2.2 3,4-Channel Chassis

The 3,4-channel chassis can accept three or four channels. The carrier gas and
power for a 3,4-channel system must be supplied externally. See

Figure 3-3

and

Figure 3-4

.

Figure 3-3 Front panel of the 3,4-channel 3000 Micro GC

Figure 3-4 Rear panel of the 3,4-channel 3000 Micro GC

Sample Inlet

RS-232 Port

RJ-45 LAN Port

Power Supply Connector

Vents
