3000 Micro GC Operating Manual
8.2.5 Remove a GC Module
The old GC Module must be physically removed from 3000 Micro GC before the
new GC Module is installed. The following procedure outlines how to remove the
left, or Channel A, GC module in a 2-channel 3000 Micro GC. The process is
similar for any channel.
CAUTION
During the module removal process, 3000 Micro GC
internal components will be exposed. To avoid damaging
3000 Micro GC, turn the power switch off and disconnect
all external power.
CAUTION - Static Sensitive Device
Electrostatic Discharge can damage electronic
components. Wear a grounded wrist strap to avoid
damaging 3000 Micro GC. A disposable, grounded wrist
strap is provided with each new module.
1 Make sure 3000 Micro GC is off (refer to section 8.1.2, Shutdown/Restart, on
page 8-3 ).
2 Remove the top cover of the 3000 Micro GC.
3 Loosen the thumbscrews in the manifold cover plate. See Figure 8-9 .
4 Remove the manifold cover plate. In the two screw design, slide the manifold
cover plate towards the GC module to disengage the hook in the cover plate
from the tab in the chassis.
