Configuration of the safe inputs
7.3 Safe configuration using ASIMON 3 G2
Start
USB
ASIMON
ASIMON 3 G2 Software
Change the preset password during the first use of the device (Monitor/change password)!
ASIMON 3 G2 Software
Create the desired configuration.
ASIMON 3 G2 Software
Download the configuration with MONITOR / PC-> MONITOR into the device. Enter the password for
this purpose.
ASIMON 3 G2 Software
Acknowledge the request TEACH CODE SEQUENCES? selecting "Yes".
ASIMON 3 G2 Software
Check the configuration log (respect instructions in of the ASIMON manual!).
ASIMON 3 G2 Software
Validate the configuration with MONITOR –> VALIDATION.
ASIMON 3 G2 Software
Start the monitor with MONITOR–> START.
The correct safety function of the device must be verified once installed within the pro-
tected machinery!
