Safety Basic Monitor

Product Description

4.11

Decoupling function

Bei activating the option "Operation without AS-i power supply" you can use the
AS-i Power24V data decoupling network instead of an external AS-i power sup-
ply.

Simply open the ‘Monitor/-Bus Information’ window in ASIMON, select the tab
’Safety Basis Monitor’ and activate the check box "Operation without AS-i power
supply".

only

SBM-11-N08 !

Information!

The internal decoupling unit can supply a maximum current of 500 mA.

ASIMON 3 G2 Software

Information!

Please note additional information in the manual for the ASIMON software.
