Safety Basic Monitor
Product Description
4.3 Safety relevant data
To determine the safety characteristics (PFD and PFH), the values of all compo-
nents using this function are to be considered. The module provides no significant
contribution to the PFD or PFH values of the complete system. For the values of
other components, please refer to relevant documentation.
4.4 Requirements for the voltage supply +24 V
EXT
(AUX)
The power supply +24 V
EXT
may only occur via SELV or PELV networks.
Characteristics Value Standard
Safety category 4 EN 954-1
EN 13 849-1:2008
Performance Level (PL) e EN 13 849-1:2008
Safety Integrity Level (SIL) 3 IEC 61 508, EN 62 061
Service life (TM) [year] 20 EN 13 849-1:2008
Maximal power-on time (month) 12 IEC 61 508
PFD
9,58 x 10
-7 EN 62 061
PFH
D
1
1. Probability of a dangerous loss per hour.
5,08 x 10
-9 IEC 61 508, EN 62 061
Max. reaction time [ms] IEC 61 508
AS-i input slave
→
local output 40
local input → local output 20
local input
→
AS-i code sequence 26
AS-i input slave
→
AS-i code sequence 45
Tab. 4-1.
Attention!
If the option „augmented reliability“ is selected the response time can extend.
Attention!
Error states of the remote outputs used in the safe configuration can be eliminated by
starting and stopping the monitor.
Information!
The externally connectable circuits are to be separated from the net absolutely reliable!
