Safety Basic Monitor
AS-i Diagnostics
6. AS-i Diagnostics
6.1 Introduction
The device provides two different diagnostics modes:
• Consortial monitor, for replacement (see chap. 6.2)
• Compatibility mode with additional diagnostics data (see chap. 6.3)
• AS-i 3.0 (S-7.5.5), recommended (see chap. 6.4)
The respective diagnostics mode is selected using the ASIMON software.
† Simply open the ‘Monitor/-Bus Information’ window in ASIMON
† Select the ‘Diagnostics/Service’ tab
† There select the required diagnostics mode.
6.1.1 Data of the different diagnostics modes
AS-i 3.0 (S-7.5.5), rec-
ommended
(see chap. 6.4) Consortial monitor,
for replacement
(see chap. 6.2) Compatibility mode
with additional diag-
nostics data
(see chap. 6.3)
base address S-7.5 communication
(see chap. 6.4.1 …
6.4.3) consortial diagnos-
tics (chap. 7.3.2 …
7.3.6 software man-
ual) consortial diagnos-
tics (chap. 7.3.2 …
7.3.6 software man-
ual)
simulate slave 1
base address+1 state OSSD1+OSSD2 state
OSSD1+OSSD2
state
OSSD1+OSSD2
simulate slave 2
base address+2 S-7.F slave,
input data = 0 S-7.F slave,
input data = 0 S-7.3.0.C slave (see
chap. 6.3)
simulate slave 3
base address+3 S-7.F slave,
input data = 0 S-7.F slave,
input data = 0 S-7.3.1.C slave (see
chap. 6.3)
Tab. 6-7.
