Safety Basic Monitor
AS-i Diagnostics
6.4.3.4 Vendor Specific Object 10 - device colors at switch off OSSD 1
with device index-assignment
Read only.
This object contains colors and additional information about all release circuits at
the time of the most recent switch-off of release circuit 1, sorted by the diagnos-
tics index. Additionally, information identifying all devices assigned to release cir-
cuit 1 is transferred.
Coding of states and colors
Byte Meaning
1
bit 0 0=configuration mode, 1=protective operation
bit 3 … 1 reserved, 0
bit 4 status S12
bit 5 status S21
bit 6 status S32
bit 7 status S41
2
relay status output 1+2
bit 3 … 0 status output 1
bit 7 … 4 status output 2
3 ... 8
...
9
relay status output 15+16
bit 3..0 status output 15
bit 7..4 status output 16
10
bit field for devices which are present. Device 7 ... 0
11 ... 40
...
41
bit field for devices which are present. Device 248 ... 255
42
bit field for devices which changed in the last step. Device 7 ... 0
43 ... 72
...
73
bit field for devices which changed in the last step. Device 248 … 255
74
color device 1+2
bit 3 … 0 color device 1
bit 7 … 4 color device 2
75 ... 200 ...
137 device 127+128
bit 3..0 color device 127
bit 7..4 color device 128
Tab. 6-32.
