Safety Basic Monitor
Product Description
4.9 Chip card
The chip card stores the addresses of the slaves. All programming operations are
stored both in the module and on the chip card.
• The device can operate both with and without a chip card.
• If a blank chip card is plugged into a programmed module, the configuration
of the module is stored on the chip card.
• If a non-blank chip card is plugged into an non-programmed module, the con-
figuration of the chip card is transmitted to the module. The changes do not
become effective until the module is restarted.
• If a non-blank chip card is plugged into a different programmed module, the
configurations do not agree and an error message is displayed.
4.10 AS-i Power 24
• internal decoupling network / AS-i voltage is generated out of 24 V
ext
directly
• no external AS-i power supply, no external decoupling unit required!
• maximum 0,5 A for AS-i available using internal decoupling network
• switching between internal and external decoupling.
only
SBM-11-N08 !
