6.4.3 Acyclical data
6.4.3.1 Vendor Specific Object 7 - device colors OSSD 1
Read only
This object contains the colors and additional information for all release circuits
for all devices assigned to Release Circuit 1.
Information!
If not all 128 devices are assigned, the Monitor can shorten the S-7.5.5 telegram in
order to save transmission time.
Coding for the states and colors
Byte Meaning
1
bit 0 0=configuration mode, 1=protecting mode
bit 3 … 1 reserved, 0
bit 4 status S12
bit 5 status S21
bit 6 status S32
bit 7 status S41
2
relay status, output 1+2
bit 3 … 0 status output 1
bit 7 … 4 status output 2
3 … 8
...
9
relay status output 15+16
bit 3 … 0 status output 15
bit 7 … 4 status output 16
10
bit field for devices which are present. Device 7 … 0
11 ... 40 ...
41
bit field for devices which are present. Device 248 … 255
42
color device 1+2
bit 3 … 0 color device 1
bit 7 … 4 color device 2
43 ... 168 ...
105
device 127+128
bit 3 … 0 color device 127
bit 7 … 4 color device 128
Tab. 6-22.
