Safety Basic Monitor
AS-i Diagnostics
^
For each safe slave (ID=B) the status of the code sequence is entered as seen by
the Master. Code sequence errors are not detected here. For non-safe slaves ‘00’
is entered.
6.3.1 Status codes for the release circuits (OSSD)
Simulated slave 3 (S-7.3.1.C)::SaW slave diagnostics
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
CH1 Slv 7 Slv 6 Slv 5 Slv 4 Slv 3 Slv 2 Slv 1
CH2 Slv 15 Slv 14 Slv 13 Slv 12 Slv 11 Slv 10 Slv 9 Slv 8
CH3 Slv 23 Slv 22 Slv 21 Slv 20 Slv 19 Slv 18 Slv 17 Slv 16
CH4 Slv 31 Slv 30 Slv 29 Slv 28 Slv 27 Slv 26 Slv 25 Slv 24
Tab. 6-14.
Bit-combination meaning
00 Not a safe slave or save slave with zero sequence, both switches
open
01 Safe slave, switch for upper bits open
10 Safe slave, switch for lower bits open
11 Safe slave, both switches closed
Tab. 6-15.
Code
bit [3..0] Status / color Description
0 green permanent lighting Output on
1 green flashing delay time is running at stop category 1
2 continuous yellow start-up/restart-disable active
3 yellow flashing External test required / acknowledgement /
Turn-on delay active
4 red permanent lighting Output off
5 red flashing Error
6 grey or off output not projected
7 ... F reserved
Tab. 6-16.
Information!
Monitors which support less than 8 release circuits do not set all release circuits
present to “grey".
