6.4.3.6
Vendor- specific object 110
Vendor specific object 110 describes the SaW slave diagnostics.
^
For each safe slave (ID=B) the status of the code sequence is entered as seen by
the Master. Code sequence errors are not detected here. For non-safe slaves ‘00’
is entered.
15
14
13 12
11
10 9
8
7
6
5
4
3
2
1
0
CH1
Slv 7
Slv 6
Slv 5
Slv 4
Slv 3
Slv 2
Slv 1
CH2
Slv 15
Slv 14
Slv 13
Slv 12
Slv 11
Slv 10
Slv 9
Slv 8
CH3
Slv 23
Slv 22
Slv 21
Slv 20
Slv 19
Slv 18
Slv 17
Slv 16
CH4
Slv 31
Slv 30
Slv 29
Slv 28
Slv 27
Slv 26
Slv 25
Slv 24
Tab. 6-37.
Bit-combination meaning
00
Not a safe slave or save slave with zero sequence, both switches
open
01
Safe slave, switch for upper bits open
10
Safe slave, switch for lower bits open
11
Safe slave, both switches closed
Tab. 6-38.
Information!
Please note additional information in the manual for the ASIMON software.
