Safety Basic Monitor
AS-i Diagnostics
6.4.3.2 Vendor Specific Object 8 - device colors OSSD
with device index assignment
Read only.
This object contains, for all devices assigned to Release Circuit 1, the colors and
additional information for all release circuits with the module index assignment
from the configuration.
Coding of the states and colors
Byte Meaning
1
bit 0 0= configuration operation , 1= protective operation
bit 3 … 1 reserved, 0
bit 4 status S12
bit 5 status S21
bit 6 status S32
bit 7 status S41
2
relay status output 1+2
bit 3 … 0 status output 1
bit 7 … 4 status output 2
3 … 8
...
9
relay status output 15+16
bit 3 … 0 status output 15
bit 7 … 4 status output 16
10
bit field for devices which are present. Device 7 … 0
11 ... 40
...
41
bit field for devices which are present. Device 248 … 255
42
color device 1+2
bit 3 … 0 color device 1
bit 7 … 4 color device 2
43 ... 168
...
105
device 127+128
bit 3 … 0 color device 127
bit 7 … 4 color device 128
Tab. 6-25.
